Instrument Cluster Services

Instrument clusters are complex modules that combine display electronics, microcontrollers, power drivers and communication networks.
Faults inside the cluster can cause incorrect readings, warning lights, backlight issues, or complete loss of display.

We provide bench-level cluster diagnostics, coding, configuration repair, EEPROM data handling and component-level work for supported models.

All work is performed safely on the bench with full data backups and verified software integrity.

What We Do

1. Instrument Cluster Diagnostics

We diagnose:

  • no communication

  • dead cluster / no power

  • intermittent operation

  • missing gauges

  • incorrect readings

  • warning lights stuck ON

  • CAN/LIN communication faults

  • corrupted EEPROM

Bench diagnostics isolate the underlying electronic or data issue.

2. EEPROM/FLASH Data Repair

We repair:

  • corrupted EEPROM blocks

  • configuration data

  • VIN/matching issues

  • immobiliser-related data (supported models only)

  • checksum errors

  • incorrect or damaged coding

Backups are created before any operation.

3. Coding & Configuration Correction

Cluster coding may become incorrect after:

  • module replacement

  • jump-start damage

  • mismatched donor cluster

  • incorrect programming attempts

  • BCM/ECU adaptations

We restore correct configuration, coding and identification.

4. Backlight & Display-Related Electronic Repair

Component-level repair for:

  • power supply circuits

  • voltage regulators

  • display drivers

  • SMD components

  • communication transceivers

No LCD replacement — only electronic repairs.

5. Mileage Correction (Legal & Verified Only)

We provide mileage correction only in legally permitted cases, such as:

  • cluster replacement

  • donor cluster mileage mismatch

  • incorrect values after programming

  • damaged EEPROM after crash or short circuit

Documentation may be required depending on jurisdiction.

(No odometer rollback for illegal purposes.)

6. Cluster Cloning (Where Supported)

1:1 cloning for supported clusters:

  • EEPROM

  • configuration

  • coding

  • immobiliser data (if applicable)

Used when replacing a failed cluster with a donor.

Typical Problems We Fix

  • dead cluster / no power

  • incorrect mileage reading

  • flickering or intermittent operation

  • non-responsive gauges

  • warning lights stuck ON

  • backlight failure

  • coding mismatch

  • VIN mismatch

  • communication faults

  • corrupted EEPROM

Supported Brands

(Based on EEPROM-based and standard PCB clusters)

  • Volkswagen / Audi / Skoda / SEAT

  • Ford

  • Nissan / Renault

  • Peugeot / Citroën

  • Opel / Vauxhall

  • Mazda

  • Toyota

  • Hyundai / Kia

  • Many others (module-dependent)

What We Do NOT Do

  • no LCD screen replacement

  • no pixel repair for BMW E-series

  • no full MCU / processor repair

  • no flooded / heavily corroded clusters

  • no illegal mileage rollback

Postal Service — Ireland, UK & EU

Send the cluster to our bench lab.

Includes:

  • diagnostics

  • EEPROM/FLASH backup

  • repair or coding

  • return shipping with tracking

  • WhatsApp updates throughout

Why Choose This Service

  • safe bench-only methods

  • accurate EEPROM/FLASH handling

  • OEM-level diagnostic tools

  • stable power and controlled programming

  • transparent reporting

  • fast, reliable turnaround
